Single phase energy meter test bench FYL-S24

l     It is a product with reasonable design and delicate appearance. The meter rack of  the testing equipment and the desk frame are all made of special  aluminum alloy and the desk faceplate @ made of fireproof and heatproof  fiber material.

l     Special keyboard operation and PC operation are available, and it is easy to operate. The  functions of the keys on the special portable keyboard are clearly identified and the LCD on the special keyboard displays the testing equipment working condition.

l     During watt-hour meter testing, what needs to do manually is to put up the meters to be tested, adjust the photoelectric sampler and setup the meter parameters correctly, then all testing items including warming up, creeping test, starting test and basic error measurement can be completed automatically by PC. The  testing procedure can refer to the national procedure or can be self-defined by the user.

l     The photoelectric sampler can realize three-dimensional adjustment. It can not  only sample the turn-plate signal of the rotary watt-hour meter but  also receive the strobe signal of the electronic watt-hour meter.

l     The error processing system can receive signal from the photoelectric sampler and output pulse of the insert type electronic watt-hour meter.

l     Watt-hour meters of same type (same phase, rated voltage and rated current) but different constant can be  tested simultaneously (only limited to two different constants).

l     Testing of the communication function of the 485 port, demand error and clocking error of the multifunction watt-hour meter is available (The meters being tested must have time signal output).

l     Locating of marking area of the rotary watt-hour meter turn-plate can be realized automatically, which enables easier creeping (starting) test.

l     The testing equipment is of high stability and reliability, which can provide strong output power. Voltage  (current) loop can take load of any type.

l     The testing equipment is provided with complete malfunction checking, locating, protecting and alarming functions to avoid damaging of the bench resulted from wrong manual wiring or operating.

l     PC software developed with Delphi for Windows 95 provides fast and effective  equipment  control and data checking, it also provides complete functions, such as  report printing, quantity counting and assets maintaining .
