Digital Monitoring Controller PM600 Series
Digital Monitoring Controller PM600 Series
Model: PM600
Name: Digital Monitoring Controller PM600 Series
Introduction: Digital Monitoring Controller PM600 Series is designed for power system enterprises and industries for monitoring and controlling. They can measure most of common use electric parameters in high accuracy,
Name: Digital Monitoring Controller PM600 Series
Introduction: Digital Monitoring Controller PM600 Series is designed for power system enterprises and industries for monitoring and controlling. They can measure most of common use electric parameters in high accuracy,
l All of these meters can be with one loop analog output and can choose the transmitting output, 4~20mA, 0~5V, 0~12~20mA etc.
l Two loop alarming output optional, limiting value monitoring for the measuring parameters.
l RS-485 interface, under MODBUS-RTU protocol.
l Wide application, more powerful combine function.
l Digital zero calibration, digital adjusting, high accuracy and high cost performance.
l It can configure the display times ratio, communication address, baud ratio and other parameters freely.
Previous：
Three phase ANSI socket energy meter
